Cisco Switch 3560-X Series WS-C3560X-24T-E Catalyst 3560X 24 Port

Cisco Catalyst WS-3560-X 24T-E Switch Description

The Cisco Catalyst WS-3560-X Switch Series helps to improve availability, scalability, security and ease of operation with innovative features. The Cisco WS-C3560X-24T-E is a 24 port Gigabit Ethernet port 1u rack mountable switch that supports four optional 1G/10G network uplink module with no stack IP Service feature.

Cisco WS-C3560X-24T-E is designed for enterprise distribution layer switching in full layer 3 capability includes BGP, EIGRP, OSFP, IPv4/v6, multicast routing, IPSLA, Netflow, advanced Qos, VRF-lite.

Dual Redundant Modular Power Supplies:

The Catalyst WS-3560-X 24T-E is designed with a single power supply module (default) with optional to purchase additional power supply module that can be inserted into the power supply bay 2 in order to power redundancy.

Software Update:

The Cisco Catalyst 3560-X series supports software upgrade features through the Cisco IOS software activation. Cisco IOS Software activates the appropriate feature set. License types can be changed, or upgraded, to activate a different feature set.

What’s In The Box?

• Cisco Catalyst 3560-X 24-port Switch
• Ethernet Cable
• Power Cable
• User Guide

Cisco WS-C3560X-24T-E Specifications ‘

• Product Type: Switch - 24 ports - L3 - Managed
• Form Factor: Rack mountable - 1U
• Switch Ports: 24 x 10/100/1000 Ethernet Ports Ethernet Ports
• Performance: Switching capacity : 160 Gbps
• Routing Protocol: RIP-1, RIP-2, HSRP, VRRP, BLGP, EIGRP, OSPF, BGP, PIM
• Remote Management Protocol: SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI
• Authentication Method: Kerberos, Secure Shell (SSH), RADIUS, TACACS+
• Features: Hot swap module replacement, Layer 3 switching, Layer 2 switching, dynamic IP address assignment , DHCP support, auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, traffic shaping, Broadcast Storm Control, High Availability, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+), EIGRP, BGP, OSPF, IPv4/v6
• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae
• DRAM Memory: 256 MB
• Flash Memory: 64 MB Flash
• Status Indicators: Port status, link activity, port transmission speed, port duplex mode, power, system

Connectivity Slots

Interfaces:

• 24 x 10Base-T/100Base-TX/1000Base-T - RJ-45
• USB : 1 x 4 PIN USB Type A
• 1 x console - mini-USB Type B - management
• 1 x RS-232 - RJ-45 - management
• 1 x 10Base-T/100Base-TX - RJ-45 - management
• Expansion Slot(s): 1 (total) / 1 (free) x Expansion Slot

Power Supply

• Power Device: Power supply - redundant - plug-in module
• Installed Qty: 1 (installed) / 2 (max)
• Power Redundancy: Optional
• Power Redundancy Scheme: 1+1 (with optional power supply)
• Voltage Required: AC 120/230 V ( 50/60 Hz )
• Features: Redundant Power System (RPS) connector

Dimensions / Weight / Miscellaneous

• Width: 44.5 cm
• Depth: 46 cm
• Height: 4.5 cm
• Weight: 7 kg
• Rack Mounting Kit: Optional

System Software

• Software Included: Cisco IOS IP Service
